AC Duck & DC Jack

AC Duck & DC Jack

AC Duck, The case of charger

AC Duck (China-Spec)

China-Spec Charger :

Power Rating (Input) : AC 100V~240V, 600mA
Power Rating (Output) : DC 11.4V~12.6V ,0~1000mA
AC Leakage Current : 0.25mA Max, at 240V AC Input
Insulation Resistance : DC 500V, 1 Minute ≧ 100MΩ
Operating Temperature : 0~40℃
Materials : PC UL94 V-0

AC Duck (European-Spec)

European-Spec Charger :

Power Rating (Input) : AC 100V~240V, 600mA
Power Rating (Output) : DC 11.4V~12.6V ,0~1000mA
AC Leakage Current : 0.25mA Max, at 240V AC Input
Insulation Resistance : DC 500V, 1 Minute ≧ 100MΩ
Operating Temperature : 0~45℃
Materials : PC UL94 V-0

AC Duck (USA-Spec)

United States-Spec charger :

Power Rating (Input) : AC 100V~240V, 600mA
Power Rating (Output) : DC 11.4V~12.6V ,0~1000mA
AC Leakage Current : 0.25mA Max, at 240V AC Input
Insulation Resistance : DC 500V, 1 Minute ≧ 100MΩ
Operating Temperature : 0~45℃
Materials : PC UL94 V-0

DC Jack

DC Jack (DC012A-2.0)

DC012A-2.0 :

Power Rating : DC 30V 0.5A
Electric Strength : AC 500V (50HZ) 1 Minute，Without insulation damage and other abnormalities
Contact Resistance : 100mA MAX ≦ 100Ω
Insulation Resistance : DC 500V, 1 Minute ≧ 100MΩ
Operating Temperature : -40~55℃
Materials : PA 66

DC Jack (DC-005-Y)

DC-005-Y :

Power Rating : DC 30V 0.5A
Electric Strength : AC 500V (50HZ) 1 Minute，Without insulation damage and other abnormalities
Contact Resistance : 100mA MAX ≦ 0.03Ω
Insulation Resistance : DC 500V, 1 Minute ≧ 100MΩ
Operating Temperature : -16~65℃
Materials : PA 66

DC012A-2.0-2BK

DC012A-2.0-2BK ( new )

Power Rating : DC 30V 0.5A
Electric Strength : AC 500V (50HZ) 1 Minute，Without insulation damage and other abnormalities
Contact Resistance : 30MΩ Max.
Insulation Resistance : 100MΩ Min. at 500V DC
Operating Temperature : -40℃~55℃
Actuating Force : 3~20N
Mechanical Life : 5000 Times
